Adjustable machine foot - MFPAS
Articulated machine feet made of glass fibre reinforced polyamide with stainless steel thread and antislip pad (A)
Your session has expired, please log in again.
Configure your article. Enter multiple parameters to get the best result.
D in mm:
F max. in kg:
H in mm:
H1 in mm:
L in mm:
M:
WAF in mm:
Your article results:
Order-No. D
mmF max.
kgH
mmH1
mmL
mmM WAF
mm- MFPAS 40 / M8x25
MFPAS 40 / M8x25 40 1000 16,5 27 25 M8 12 - MFPAS 40 / M8x25 A
MFPAS 40 / M8x25 A 40 1000 16,5 27 25 M8 12 - MFPAS 40 / M8x50
MFPAS 40 / M8x50 40 1000 16,5 27 50 M8 12 - MFPAS 40 / M8x50 A
MFPAS 40 / M8x50 A 40 1000 16,5 27 50 M8 12 - MFPAS 40 / M8x75
MFPAS 40 / M8x75 40 1000 16,5 27 75 M8 12 - MFPAS 40 / M8x75 A
MFPAS 40 / M8x75 A 40 1000 16,5 27 75 M8 12 - MFPAS 40 / M8x100
MFPAS 40 / M8x100 40 1000 16,5 27 100 M8 12 - MFPAS 40 / M8x100 A
MFPAS 40 / M8x100 A 40 1000 16,5 27 100 M8 12 - MFPAS 40 / M10x25
MFPAS 40 / M10x25 40 1000 16,5 27 25 M10 12 - MFPAS 40 / M10x25 A
MFPAS 40 / M10x25 A 40 1000 16,5 27 25 M10 12 - MFPAS 40 / M12x25
MFPAS 40 / M12x25 40 1000 16,5 27 25 M12 12 - MFPAS 40 / M12x25 A
MFPAS 40 / M12x25 A 40 1000 16,5 27 25 M12 12 - MFPAS 40 / M10x50
MFPAS 40 / M10x50 40 1000 16,5 27 50 M10 12 - MFPAS 40 / M10x50 A
MFPAS 40 / M10x50 A 40 1000 16,5 27 50 M10 12 - MFPAS 40 / M12x50
MFPAS 40 / M12x50 40 1000 16,5 27 50 M12 12 - MFPAS 40 / M12x50 A
MFPAS 40 / M12x50 A 40 1000 16,5 27 50 M12 12 - MFPAS 40 / M10x75
MFPAS 40 / M10x75 40 1000 16,5 27 75 M10 12 - MFPAS 40 / M10x75 A
MFPAS 40 / M10x75 A 40 1000 16,5 27 75 M10 12 - MFPAS 40 / M12x75
MFPAS 40 / M12x75 40 1000 16,5 27 75 M12 12 - MFPAS 40 / M12x75 A
MFPAS 40 / M12x75 A 40 1000 16,5 27 75 M12 12 - MFPAS 40 / M10x100
MFPAS 40 / M10x100 40 1000 16,5 27 100 M10 12 - MFPAS 40 / M10x100 A
MFPAS 40 / M10x100 A 40 1000 16,5 27 100 M10 12 - MFPAS 40 / M12x100
MFPAS 40 / M12x100 40 1000 16,5 27 100 M12 12 - MFPAS 40 / M12x100 A
MFPAS 40 / M12x100 A 40 1000 16,5 27 100 M12 12 - MFPAS 40 / M10x125
MFPAS 40 / M10x125 40 1000 16,5 27 125 M10 12 - MFPAS 40 / M10x125 A
MFPAS 40 / M10x125 A 40 1000 16,5 27 125 M10 12 - MFPAS 40 / M12x125
MFPAS 40 / M12x125 40 1000 16,5 27 125 M12 12 - MFPAS 40 / M12x125 A
MFPAS 40 / M12x125 A 40 1000 16,5 27 125 M12 12 - MFPAS 50 / M10x25
MFPAS 50 / M10x25 50 1100 20 30 25 M10 14 - MFPAS 50 / M10x25 A
MFPAS 50 / M10x25 A 50 1100 20 30 25 M10 14 - MFPAS 50 / M10x50
MFPAS 50 / M10x50 50 1100 20 30 50 M10 14 - MFPAS 50 / M10x50 A
MFPAS 50 / M10x50 A 50 1100 20 30 50 M10 14 - MFPAS 50 / M10x75
MFPAS 50 / M10x75 50 1100 20 30 75 M10 14 - MFPAS 50 / M10x75 A
MFPAS 50 / M10x75 A 50 1100 20 30 75 M10 14 - MFPAS 50 / M10x100
MFPAS 50 / M10x100 50 1100 20 30 100 M10 14 - MFPAS 50 / M10x100 A
MFPAS 50 / M10x100 A 50 1100 20 30 100 M10 14 - MFPAS 50 / M10x125
MFPAS 50 / M10x125 50 1100 20 30 125 M10 14 - MFPAS 50 / M10x125 A
MFPAS 50 / M10x125 A 50 1100 20 30 125 M10 14 - MFPAS 50 / M12x25
MFPAS 50 / M12x25 50 1100 20 30 25 M12 14 - MFPAS 50 / M12x25 A
MFPAS 50 / M12x25 A 50 1100 20 30 25 M12 14 - MFPAS 50 / M12x50
MFPAS 50 / M12x50 50 1100 20 30 50 M12 14 - MFPAS 50 / M12x50 A
MFPAS 50 / M12x50 A 50 1100 20 30 50 M12 14 - MFPAS 50 / M12x75
MFPAS 50 / M12x75 50 1100 20 30 75 M12 14 - MFPAS 50 / M12x75 A
MFPAS 50 / M12x75 A 50 1100 20 30 75 M12 14 - MFPAS 50 / M12x100
MFPAS 50 / M12x100 50 1100 20 30 100 M12 14 - MFPAS 50 / M12x100 A
MFPAS 50 / M12x100 A 50 1100 20 30 100 M12 14 - MFPAS 50 / M12x125
MFPAS 50 / M12x125 50 1100 20 30 125 M12 14 - MFPAS 50 / M12x125 A
MFPAS 50 / M12x125 A 50 1100 20 30 125 M12 14 - MFPAS 50 / M14x25
MFPAS 50 / M14x25 50 1100 20 30 25 M14 14 - MFPAS 50 / M14x25 A
MFPAS 50 / M14x25 A 50 1100 20 30 25 M14 14 - MFPAS 50 / M14x50
MFPAS 50 / M14x50 50 1100 20 30 50 M14 14 - MFPAS 50 / M14x50 A
MFPAS 50 / M14x50 A 50 1100 20 30 50 M14 14 - MFPAS 50 / M14x75
MFPAS 50 / M14x75 50 1100 20 30 75 M14 14 - MFPAS 50 / M14x75 A
MFPAS 50 / M14x75 A 50 1100 20 30 75 M14 14 - MFPAS 50 / M14x100
MFPAS 50 / M14x100 50 1100 20 30 100 M14 14 - MFPAS 50 / M14x100 A
MFPAS 50 / M14x100 A 50 1100 20 30 100 M14 14 - MFPAS 50 / M14x125
MFPAS 50 / M14x125 50 1100 20 30 125 M14 14 - MFPAS 50 / M14x125 A
MFPAS 50 / M14x125 A 50 1100 20 30 125 M14 14 - MFPAS 65 / M10x50
MFPAS 65 / M10x50 65 1100 23 33 50 M10 14 - MFPAS 65 / M10x50 A
MFPAS 65 / M10x50 A 65 1100 23 33 50 M10 14 - MFPAS 65 / M10x75
MFPAS 65 / M10x75 65 1100 23 33 75 M10 14 - MFPAS 65 / M10x75 A
MFPAS 65 / M10x75 A 65 1100 23 33 75 M10 14 - MFPAS 65 / M10x100
MFPAS 65 / M10x100 65 1100 23 33 100 M10 14 - MFPAS 65 / M10x100 A
MFPAS 65 / M10x100 A 65 1100 23 33 100 M10 14 - MFPAS 65 / M10x125
MFPAS 65 / M10x125 65 1100 23 33 125 M10 14 - MFPAS 65 / M10x125 A
MFPAS 65 / M10x125 A 65 1100 23 33 125 M10 14 - MFPAS 65 / M12x50
MFPAS 65 / M12x50 65 1100 23 33 50 M12 14 - MFPAS 65 / M12x50 A
MFPAS 65 / M12x50 A 65 1100 23 33 50 M12 14 - MFPAS 65 / M12x75
MFPAS 65 / M12x75 65 1100 23 33 75 M12 14 - MFPAS 65 / M12x75 A
MFPAS 65 / M12x75 A 65 1100 23 33 75 M12 14 - MFPAS 65 / M12x100
MFPAS 65 / M12x100 65 1100 23 33 100 M12 14 - MFPAS 65 / M12x100 A
MFPAS 65 / M12x100 A 65 1100 23 33 100 M12 14 - MFPAS 65 / M12x125
MFPAS 65 / M12x125 65 1100 23 33 125 M12 14 - MFPAS 65 / M12x125 A
MFPAS 65 / M12x125 A 65 1100 23 33 125 M12 14 - MFPAS 65 / M14x50
MFPAS 65 / M14x50 65 1500 23 33 50 M14 14 - MFPAS 65 / M14x50 A
MFPAS 65 / M14x50 A 65 1500 23 33 50 M14 14 - MFPAS 65 / M14x75
MFPAS 65 / M14x75 65 1500 23 33 75 M14 14 - MFPAS 65 / M14x75 A
MFPAS 65 / M14x75 A 65 1500 23 33 75 M14 14 - MFPAS 65 / M14x100
MFPAS 65 / M14x100 65 1500 23 33 100 M14 14 - MFPAS 65 / M14x100 A
MFPAS 65 / M14x100 A 65 1500 23 33 100 M14 14 - MFPAS 65 / M14x125
MFPAS 65 / M14x125 65 1500 23 33 125 M14 14 - MFPAS 65 / M14x125 A
MFPAS 65 / M14x125 A 65 1500 23 33 125 M14 14 - MFPAS 65 / M14x150
MFPAS 65 / M14x150 65 1500 23 33 150 M14 14 - MFPAS 65 / M14x150 A
MFPAS 65 / M14x150 A 65 1500 23 33 150 M14 14 - MFPAS 65 / M14x175
MFPAS 65 / M14x175 65 1500 23 33 175 M14 14 - MFPAS 65 / M14x175 A
MFPAS 65 / M14x175 A 65 1500 23 33 175 M14 14 - MFPAS 65 / M16x50
MFPAS 65 / M16x50 65 1500 23 37 50 M16 13 - MFPAS 65 / M16x50 A
MFPAS 65 / M16x50 A 65 1500 23 37 50 M16 13 - MFPAS 65 / M16x75
MFPAS 65 / M16x75 65 1500 23 37 75 M16 13 - MFPAS 65 / M16x75 A
MFPAS 65 / M16x75 A 65 1500 23 37 75 M16 13 - MFPAS 65 / M16x100
MFPAS 65 / M16x100 65 1500 23 37 100 M16 13 - MFPAS 65 / M16x100 A
MFPAS 65 / M16x100 A 65 1500 23 37 100 M16 13 - MFPAS 65 / M16x125
MFPAS 65 / M16x125 65 1500 23 37 125 M16 13 - MFPAS 65 / M16x125 A
MFPAS 65 / M16x125 A 65 1500 23 37 125 M16 13 - MFPAS 65 / M16x150
MFPAS 65 / M16x150 65 1500 23 37 150 M16 13 - MFPAS 65 / M16x150 A
MFPAS 65 / M16x150 A 65 1500 23 37 150 M16 13 - MFPAS 65 / M16x175
MFPAS 65 / M16x175 65 1500 23 37 175 M16 13 - MFPAS 65 / M16x175 A
MFPAS 65 / M16x175 A 65 1500 23 37 175 M16 13 - MFPAS 65 / M16x200
MFPAS 65 / M16x200 65 1500 23 37 200 M16 13 - MFPAS 65 / M16x200 A
MFPAS 65 / M16x200 A 65 1500 23 37 200 M16 13 - MFPAS 65 / M20x50
MFPAS 65 / M20x50 65 1500 23 37 50 M20 17 - MFPAS 65 / M20x50 A
MFPAS 65 / M20x50 A 65 1500 23 37 50 M20 17 - MFPAS 65 / M20x75
MFPAS 65 / M20x75 65 1500 23 37 75 M20 17 - MFPAS 65 / M20x75 A
MFPAS 65 / M20x75 A 65 1500 23 37 75 M20 17 - MFPAS 65 / M20x100
MFPAS 65 / M20x100 65 1500 23 37 100 M20 17 - MFPAS 65 / M20x100 A
MFPAS 65 / M20x100 A 65 1500 23 37 100 M20 17 - MFPAS 65 / M20x125
MFPAS 65 / M20x125 65 1500 23 37 125 M20 17 - MFPAS 65 / M20x125 A
MFPAS 65 / M20x125 A 65 1500 23 37 125 M20 17 - MFPAS 65 / M20x150
MFPAS 65 / M20x150 65 1500 23 37 150 M20 17 - MFPAS 65 / M20x150 A
MFPAS 65 / M20x150 A 65 1500 23 37 150 M20 17 - MFPAS 65 / M20x175
MFPAS 65 / M20x175 65 1500 23 37 175 M20 17 - MFPAS 65 / M20x175 A
MFPAS 65 / M20x175 A 65 1500 23 37 175 M20 17 - MFPAS 65 / M20X200
MFPAS 65 / M20X200 65 1500 23 37 200 M20 17 - MFPAS 65 / M20x200 A
MFPAS 65 / M20x200 A 65 1500 23 37 200 M20 17
