Sichtstopfen mit chrom-/nickelfarbener Metallabdeckung für Quadratrohre Sight plugs with chrome-/nickel-coloured metal cover for square tubes CQM CQM Bestellnummer Order Number A A mm L L mm t t mm CQM 16 16 9 1,5(2) CQM 18 18 9 1,5-2 CQM 20 20 10 1,5-2 CQM 25 25 10 1,5-2 CQM 30 30 10 (1)1,5-2 CQM 35 35 12 (1)1,5-2 CQM 40 40 12 (1)1,5-2 Standardfarben • chrom-/ nickelfarben Standard Colours • chrome-/ nickel coloured Material • Polyethylen (PE) Material • Polyethylene (PE) Gruppe / Group: CGQ Glanzverchromte Sichtstopfen für Quadratrohre Bright chrome plated sight plugs for square tubes CGQ CGQ Bestellnummer Order Number A A mm L L mm t t mm CGQ 12x12x1 12 7 1 CGQ 12x12x1,2 12 7 1,2 CGQ 15x15x1 15 8,5 1 CGQ 15x15x1,2 15 8,5 1,2 CGQ 15x15x1,5 15 8,5 1,5 CGQ 16x16x1 16 8 1 CGQ 16x16x1,5 16 8 1,5 CGQ 18x18x1,2 18 8 1,2 CGQ 18x18x1,5 18 8 1,5 CGQ 20x20x1 20 7 1 CGQ 20x20x1,2 20 7 1,2 CGQ 20x20x1,5 20 7 1,5 Bestellnummer Order Number A A mm L L mm t t mm CGQ 25x25x1 25 7 1 CGQ 25x25x1,2 25 7 1,2 CGQ 25x25x1,5 25 7 1,5 CGQ 25x25x2 25 7 2 CGQ 30x30x1 30 10 1 CGQ 30x30x1,2 30 10 1,2 CGQ 30x30x1,5 30 10 1,5 CGQ 35x35x1,2 35 11 1,2 CGQ 35x35x1,5 35 11 1,5 CGQ 40x40x1,2 40 11 1,2 CGQ 40x40x1,5 40 11 1,5 CGQ 45x45x1,2 45 11 1,2 Bestellnummer Order Number A A mm L L mm t t mm CGQ 45x45x1,5 45 11 1,5 CGQ 50x50x1,2 50 11 1,2 CGQ 50x50x1,5 50 11 1,5 CGQ 50x50x2 50 11 2 CGQ 50x50x3 50 11 3 CGQ 60x60x1,2 60 12 1,2 CGQ 60x60x1,5 60 12 1,5 CGQ 80x80x1,2 80 12 1,2 CGQ 80x80x1,5 80 12 1,5 CGQ 80x80x2 80 12 2 Standardfarben • chrom-/ nickelfarben Standard Colours • chrome-/ nickel coloured Material • ABS Material • ABS Quadratische und rechteckige Sichtstopfen Square and rectangular viewing plugs Gruppe / Group: CQM https://www.b-plastic.com 276 Index
